Fabric Braided


GH585 GH586
2556
FC332
Click link for pdf datasheet GH585
GH586
2556
FC332
Standard
EN854/2TE
EN854/3TE
EN854
Exceeds 100 R6
Temperature
-40°C to +100°C (+70°C for air)
-40°C to +100°C (+70°C for air)
-40°C to +100°C (+70°C for air)
-40°C to +150°C (+120°C for air)
Size
-3 to -16
-3 to -20
-4 to -12
-4 to -12
Working Pressure
80 to 40 bar
160 to 45 bar
25 to 17 bar
17 bar (Hi temp)

Application
Hydraulic systems with petroleum base fluids for fuel and lubricating oils, air and water.

Construction
GH585 - Synthetic NBR rubber tube, textile reinforcement. Synthetic rubber cover
GH586 - Synthetic NBR rubber tube, textile reinforcement. Synthetic rubber cover
2556 - Synthetic NBR rubber tube, textile reinforcement. Synthetic rubber cover
FC332 - AQP elastomer tube, textile braid reinforcement, AQP elastomer cover.

Hose Fittings Available - (subject to hose type)
BSPP, BSPT, JIC, SAE inverted flare, NPT, ORFS, SAE 3000, metric light (L Series).

Alternatives
Higher pressure - use 1wire/2wire - check bend radius
